Engineering 11 Unit 15 (Revolve)

Front

The Command we use in Inventor to give a sketch thickness in a straight line

Back

Extrude Command

Front

The Command we use in Inventor to give a sketch thickness in a circular path.

Back

Revolve Command

Front

An imaginary line about which a body rotates.

Back

Axis

Front

This point in Inventor (0,0) is known as the ____________?

Back

Origin Point

Front

Command used to create thin-walled objects with a consistent wall thickness.

Back

Shell Command

Front

Use this tool to extrude to a specific distance.

Back

Extrude To a Distance

Front

An Angle that is designed in a part to provide easy removal from the mold. This is also part of the Extrude Command.

Back

Draft Angle (Taper)

Front

Tool to straighten parts in inventor: See, Fix Object, Look At

Back

Look At

Front

Formulas in inventor to describe Dimensioned (d1,d2, d1+d7)

Back

Dimension Functions

Front

Use this tool to create a copy of a sketch profile inside or outside of itself.

Back

Offset
