Why does the Engineering Notebook have to be in pen or permanent ink?

Because the engineering notebook can be used during legal proceedings during a patent dispute.

What values does the block return?

TRUE (pressed) or FALSE (released).

What will happen when the Bumper Sensor is pressed in this project?

The VR Robot will drive in reverse for 200 millimeters (mm).

How could you use the Bumper Sensor in the Wall Maze challenge?

To instruct the VR Robot to turn when it bumps into a wall.

What do non-waiting blocks do in a VEXcode VR project?

They allow the stack to continue even if the block's behavior is not yet complete.

Which statement is TRUE for waiting blocks? Options: They wait for the user to select the "Step" button., They wait until the VR Robot has enough power to complete the task., They allow the rest of the stack to continue even if that block's behavior has not been completed., They pause the stack until that block's behavior has been completed.

They pause the stack until that block's behavior has been completed.

What does the highlighting feature do when a waiting block is being executed?

A highlight will appear around the block until the behavior is complete.

How often will the [Wait until] block check a Boolean condition?

It will check repeatedly until the Boolean reports TRUE.

How is the block used in this project?

It checks the condition of the Bumper Sensor. When TRUE, the VR Robot will turn right 180 degrees.

How do you change a [Drive for] block from waiting to non-waiting?

Select the arrow to expand "and don't wait".

What is the order in which behaviors will be executed in this project? Options: Drive Forward until Left Bumper is pressed, Turn right for 90 degrees, Drive Forward until Left Bumper is pressed, Turn Left for 90 degrees, Drive Forward., Drive Forward; Turn Right for 90 degrees; Drive Forward when Left Bumper is pressed; Turn Left for 90 degrees: Drive Forward when Left Bumper is Pressed., Drive Forward until Right Bumper is pressed, Turn Left for 90 degrees, Drive Forward, Turn Left for 90 degrees, Drive Forward., Drive Forward, Turn Right for 90 degrees, Drive Forward until Left Bumper is pressed, Turn Left for 90 degrees, Drive Forward until Left Bumper is Pressed.

Drive Forward until Left Bumper is pressed, Turn right for 90 degrees, Drive Forward until Left Bumper is pressed, Turn Left for 90 degrees, Drive Forward.

Which is NOT a reason to use a condition in a VEXcode VR project? Options: To utilize sensors in a project., To control the flow of a project., To create the best way for the VR Robot to run properly in a specific playground., To instruct the VR Robot to perform different behaviors depending on the conditional values that are reported.

To control the flow of a project.

Where is the "Step" function located on the VEX VR interface? Options: In the File menu., In the Monitor Window., On the Dashboard., In the toolbar between the "Start" and "Stop" buttons.

In the toolbar between the "Start" and "Stop" buttons.

Which of the following is NOT a reason to use the "Step" feature? Options: To allow the user to observe a program and behaviors, one block at a time., To step backwards through a project., To trace the flow of a project in order to find and fix problems., To visualize which blocks are being executed at a given moment.

To step backwards through a project.

This project was used to drive the VR Robot from Start to the number '1' in the Wall Maze Playground, but does not work correctly. What is the error?

The last [Turn for] should be right instead of left.

Which of the following is the best description of the [Drive for] block? Options: Moves the VR Robot backward indefinitely., Moves the VR Robot left or right., Moves the VR Robot forward or backwards a specific distance., Moves the VR Robot forward indefinitely.

Moves the VR Robot forward or backwards a specific distance.

How can you make the VR Robot move in reverse on the [Drive for] block?

Changing the "forward" parameter to "reverse".

Which of the following is the best description of what the Distance Sensor does in a project? Options: To report the location angle of the VR Robot., To change behaviors of the VR Robot if pressed., To measure the distance between the front of the Distance Sensor and the object., To report the current heading of the VR Robot.

To measure the distance between the front of the Distance Sensor and the object.

Which of the following best describes how the Distance Sensor works? Options: The Distance Sensor uses the time it takes for ultrasonic waves to reach an object from the sensor., The Distance Sensor uses the time it takes for ultrasonic waves to bounce off of an object and return to the sensor., The Distance Sensor uses the time it takes for the VR Robot to reach all objects in the Playground., The Distance Sensor uses the time it takes for ultrasonic waves to bounce off yellow and orange objects and return to the sensor.

The Distance Sensor uses the time it takes for ultrasonic waves to bounce off of an object and return to the sensor.

Which of the following best describes what the block reports?

If the first value is larger than the second value.

Which of the following best describes what the Distance Sensor reports? Options: The time it takes the VR Robot to travel around the entire playground., The distance between the VR Robot and the Distance Sensor., The distance between the VR Robot and the nearest solid object., The total distance the VR Robot travels.

The distance between the VR Robot and the nearest solid object.

In this example project the VR Robot should get to the number "2" in the Wall Maze, but it does not. Which of the following describes the error in this project? A [Drive for] block is missing., A block was used instead of a Block., A [Turn for] block was used instead of [Turn] block., A [Turn to rotation] block is missing.

A block was used instead of a Block.

Which is an advantage of being able to monitor sensor values in the Monitor Console when creating VEXcode VR projects?

Allows the user to see what is happening in a VEXcode VR project in real time.

Which of the following describes how the VR Robot will move in this project? Options: The VR Robot will start driving and stop when the Distance Sensor is greater than 150 millimeters (mm) away from an object., The VR Robot will start driving and stop when the Distance Sensor is less than 150 millimeters (mm) away from an object., The VR Robot will drive 150 millimeters (mm) then stop., The VR Robot will drive forward, stop, drive forward again for 150 millimeters (mm) then stop.

The VR Robot will start driving and stop when the Distance Sensor is less than 150 millimeters (mm) away from an object.

How can you monitor the value of the Distance Sensor in the Monitor Console? Options: Select the checkbox next to the (Position of Robot) block., Select the checkbox next to the block., Select the checkbox next to the block., Select the checkbox next to the or (Distance from) block.

Select the checkbox next to the or (Distance from) block.

Which of the following describes why the VR Robot will not move in this example project? Options: The distance between the Distance Sensor and the object is less than 150 millimeters (mm) away., The Eye Sensor is reporting the color red., The distance between the Distance Sensor and the object is greater than 150 millimeters (mm) away., The VR Robot will immediately crash into a wall if it moves.

The distance between the Distance Sensor and the object is greater than 150 millimeters (mm) away.

Which of the following best describes what the block reports? Options: If the first value is less than the second value., If the first value is larger than the second value., If the first value and the second value are equal., The second value.

If the first value is less than the second value.

Robotics I Fall Semester Test Flashcards

Student preview

50 questions

Show all answers

1.

FLASHCARD QUESTION

Front

When you make an error: Scratch it out completely, Erase it, Draw a line through it, X it out

Back

Draw a line through it

2.

FLASHCARD QUESTION

Front

Why is digital data in computers represented by binary?

Back

It's easier, cheaper, and more reliable to build machines and devices that only have to distinguish between binary states.

3.

FLASHCARD QUESTION

Front

Convert the binary (base-2) number 1001 to decimal (base-10).

Back

9

4.

FLASHCARD QUESTION

Front

Convert the decimal (base-10) number 20 to binary (base-2).

Back

10100

5.

FLASHCARD QUESTION

Front

What are the only two numbers you can use in binary?

Back

0 and 1

6.

FLASHCARD QUESTION

Front

A bit is

Back

the smallest unit of data in a computer.

7.

FLASHCARD QUESTION

Front

8 bytes = 1 bit

Back

False
