Chassis level 3

The presence of air in a hydraulic braking system will cause:

• a) a very 'spongy' brake pedal during braking
• b) corrosion of the brake lines and pistons

• c) a significant reduction in braking efficiency

• d) the brake fluid to boil under prolonged braking


A driver complains of steering wheel 'shimmy' that gets worse as the vehicle's speed increases. This most likely indicates:

• a) the tyre pressures are too high

• b) the front wheels need balancing

• c) the wheel alignment needs adjusting
• d) the shock absorbers' need replacing


Which of the following faults could be caused by worn shock absorbers?

• Increase in braking distance.
• b) Poor vehicle acceleration

• c) Reduced road spring oscillation

• d) Decrease in braking distance


ONE advantage of alloy road wheels compared with steel road wheels is they:

• a) increase unsprung weight

• b) reduce unsprung weight

• c) are cheap to manufacture

• d) reduce heat transfer


In relation to steering geometry 'camber angle' is defined as:

• a) the outward or inward tilt of the road wheel

• b) the angle between the kingpin and the wheel

• c) the backward tilt of the kingpin or swivel pin

• d) the inward tilt of the kingpin or swivel pin

In the picture of a brake caliper, what is the function of the component labelled 2?

• a) To hold the brake disc to the wheel

• b) To ensure the brake disc runs true
• c) To pull the brake pads away from the disc
• d) To push the brake pads against the disc


In a hydraulic power steering system the maximum pressure is limited by the:

• a) hydraulic pump
• b) MAP sensor

• c) control valve
• d) relief valve


In relation to a vehicle, what does the abbreviation “VIN” mean?

• a) Vehicle Information Number

• b) Vehicle Identification Number

• c) Vehicle Interpretation Number
• d) Vehicle Introduction Number


One possible cause of a vehicle pulling to the left hand side from the straight-ahead position is:

• a) incorrect nearside tyre pressures

• b) worn off side wheel bearing

• c) offside front brake binding

• d) worn offside front damper

At high speed the steering system suffers from a vibration which is not wheel balancing.One possible cause is:

• a) worn suspension dampers

• b) incorrect tyre pressures
• c) a seized track rod end
• d) a faulty ABS sensor
