AP CSP Unit 2 Review

Which of the following best describes the protocols used on the Internet?

• The protocols of the Internet are designed by government agencies to ensure they remain free to use

• The protocols of the Internet are secret to maintain the privacy and security of people using them

• Each device connected to the Internet will use a protocol designed by the company that manufactured it

• The protocols of the Internet are open and used by all devices connected to the network

Jesse purchases a new smartphone and is immediately able to use it to send a photo over the Internet to a friend who lives in a different country. Which of the following is NOT necessary to make this possible?

• Both devices are using the same shared and open protocols

• A single direct connection is established between any two devices connected to the Internet

• The data of the image is routed through a sequence of directly connected devices before arriving at its destination.

• Both devices are directly connected to at least one part of the Internet

This diagram shows a number of computing devices connected to the Internet with each line representing a direct connection. Device A is attempting to send data over the Internet to Device E. Which of the following is true of how the data will travel through the network?

• The data will always travel through Device B as it is the shortest path

• The data will never be sent to Device G since there are other shorter paths available

• It is possible that the data travels through any of the devices in the network before arriving at device E

• If the data travels through Device D then it will not travel through Device B

Which of the following is true of how the Internet has responded to the increasing number of devices now using the network?

• The Internet protocols are changed every year to adapt to the new devices that have been connected to the network

• While the number of devices connected to the Internet has grown, the network itself has not grown

• The protocols of the Internet were designed to scale as new devices are added

• The protocols of the Internet are no longer necessary thanks to the large number of devices now connected to the network

Which of the following is true of how packets are sent through the Internet?

• Packet metadata is only included on important packets to indicate they should get access to faster paths through the network

• Packet metadata is used to route and reassemble information travelling through the Internet

• Information sent through the internet is only encapsulated in packets if the message is too large to be sent as a datastream

• Information sent through the internet is split into two packets, one which contains the message and another which contains the metadata

Which of the following Internet protocols is MOST important in reassembling packets and requesting missing packets to form complete messages?

• Transmission Control Protocol (TCP)

• Internet Protocol (IP)

• User Datagram Protocol (UDP)

• HyperText Transfer Protocol (HTTP)

Which of the following Internet protocols is used to request and send pages and files on the World Wide Web using GET requests?

• Transmission Control Protocol (TCP)

• Internet Protocol (IP)

• User Datagram Protocol (UDP)

• HyperText Transfer Protocol (HTTP)

• Domain Name Service (DNS)

An Internet Service Provider (ISP) is a company that builds the routers and wired connections that allow individuals to access the Internet. An ISP is considering adding additional redundant connections to its network. Which of the following best describes why the company would choose to do so?

• It costs less to design a network that is redundant

• The protocols of the Internet only work on networks that are redundant

• Redundant networks are more reliable

• Adding additional connections reduces the fault-tolerance of the network

Rosa typed a URL into their web browser. After a few seconds the browser loaded the webpage.

Select ALL of the protocols that were used by the browser in fetching (requesting) webpage?

• IP

• IMAP

• POP

• HTTP

• HTML

Answer explanation

HTML displays the webpage, it is not involved in fetching or loading the webpage.

What is the primary function of the Internet Protocol (IP) in network communication?

• • To encrypt data for secure transmission.

• • To assign unique addresses to devices for identification.

• • To manage the physical connection between devices.

• • To provide a user interface for network configuration.
