What is a structure?
support the force at all times
appear or disappear depending on external conditions
is a set of elements united with each other, with the mission of supporting the forces acting on them
Combine materials like pillars, columns,...
What kinds of forces are there?
Tension or traction, compression, bending, torsion, shear
Natural and artificial
Fixed or permanent, variables, static, dynamic
Massive, vaulted
What kind of structure is this?
Natural
Beams
Created by nature
None of the above
What conditions must a structure meet?
Stability, natural, artificial, triangulation
Stability, rigidity, artificial
Tension, bending, traction
Stability, resistance, rigidity
What is the method to make the structure more rigid?
Pillars and beams
Triangulation
Arches, vaults and domes
Make the structure bigger and make a base also bigger
What kind of effort is seen in the image?
Shear
Traction
Bending
None of the above is correct
Which of these images are massive structures?
In what type of structures are pillars used?
Framework structures
Massive structures
Hanging structures
Laminated structures
What type of structure is the Eiffel Tower?
Laminated structures
Triangulated structures
Hanging structures
Vaulted structures
List 3 natural structures and 3 artificial ones
The compression is...
is when forces tryto cut the structure
is when forces try to curve or bend the structure
is when forces try to stretch or enlarge the structure
is when forces try to press the structure
Try to draw an example of traction
What is the shear?
shear is when forces try to twist the structure
shear is when forces try to cut the structure
shear is when forces try to bend the structure
When forces that tend to twist the object is...
Compression
Torsion
Shear
Bending
