WorksheetsSFT3053 Quiz 1
Total questions: 12
Worksheet time: 17mins
Crystal structure of solid is divided into 2 main categories:
Solid Polymer
Solid Crystal
Solid liquid
Solid Amorphous
The kid is eating cotton candy which is a good example of
solid crystal
solid amorphous
solid liquid
solid state
Match the Primitive (P) of Non Primitive (NP) cell in the figure.
All are Wigner-Seitz cell characteristic except:
Primitive cell
First Brillouin zone
Cell volume is maximum
A crystal with 1 atom
Match the following unit cell with the number of atom within it.
1
2
4
Reorder the following on
the steps taken to calculate the Packing Efficiency of a crystal
Calculate the volume of the unit cell
Count how many atoms there are per unit cell
Calculate the volume of a single atom
Multiply by the number of atoms in the unit cell
Divide this result by the volume of the unit cell
(a) is an example of combination of solid crystal and solid amorphous.
Reorder the following on
the steps taken to obtain the Miller Indices: Crystallographic Planes
Intercepts
Reciprocals
Reduction
Miller Indices
The _____ method helps in determining the orientation of single crystals using
white radiation in a reflected or transmitted geometry (1912).
Braggs
Laue
Einstein
Wigner
The wavelengths of first-order X-rays are 2.20 x 10-10 at 27°.
Find the distance between the adjacent Miller planes.
4.44 x 10-10
1.32 x 10-10
1.21 x 10-10
2.42 x 10-10
This image is a mirror image
This image is fold/rotational symettry
