Path I & II Practice Math, Desired Ventilation & Vent Scenarios

Total questions: 27

Worksheet time: 54mins

Name
Class
Date
1.
A patient receiving mechanical ventilation has a peak inspiratory pressure (PIP) of 60 cmH2O and a plateau pressure of 45 cmH2O. The ventilator flow rate is set at 60 L/min. What is the patient’s airway resistance?
a)
30 cm H2O/L
b)
45 cm H2O/L/sec
c)
15 cm H2O/L/sec
d)
25 cm H2O/L/sec
2.
What is the normal value of the A-a gradient?
a)
5 mmHg
b)

300 mmHg

c)

35 mmHg

d)

80 mmHg

3.
The physician has requested the dynamic compliance measurement for an adult patient who is receiving mechanical ventilation. This value can be obtained by dividing the patient’s tidal volume by what?
a)
PIP – PEEP
b)
PEEP – PIP
c)
Pplat – PEEP
d)
Pplat – PIP
4.
The doctor has requested the static compliance measurement for an adult patient who is receiving mechanical ventilation. This value can be obtained by dividing the patient’s tidal volume by what?
a)
Pplat – PEEP
b)
PIP – PEEP
c)
PEEP – PIP
d)
PIP – Pplat
5.
An H cylinder is half full (full = 2,200), and the patient is receiving oxygen via nasal cannula at 3 L/min. How long will the cylinder last in minutes and in hours?
a)
1,151 minutes or 19.18 hours
b)
1,380 minutes or 23.0 hours
c)
920 minutes or 15.33 hours
d)
760 minutes or 12.67 hours
6.
An E cylinder is at 1,400 psi, and the flow rate is 2.5 L/min. How many minutes will the tank last?
a)

156 minutes

b)

202 minutes

c)

241 minutes

d)

309 minutes

7.
If a patient has smoked 2 packs of cigarettes daily for the past 35 years, what would their pack year history be?
a)
70 pack years
b)
105 pack years
c)
140 pack years
d)
175 pack years
8.
What is the formula for minute ventilation?
a)
MV = Respiratory Rate x Tidal Volume
b)
MV = Respiratory Rate ÷ Tidal Volume
c)
MV = Respiratory Rate + Tidal Volume
d)
MV = Respiratory Rate - Tidal Volume
9.
A 36-year-old female patient has a respiratory rate of 12 and a tidal volume of 500 mL. What is the minute ventilation?
a)
6 L/min
b)
7.5 L/min
c)
9 L/min
d)
10.5 L/min
10.

A 50-year-old male with ARDS, height 70 inches, weight 100kg, is on AC/VC with Vt: 400, f: 22, FiO2: 0.70, PEEP: +12. Plateau pressure is 32cmH2O. What's the most appropriate action?

a)

Increase tidal volume to 450mL

b)

Decrease PEEP to +10

c)

Reduce tidal volume to 350mL

d)

Increase respiratory rate to 24

11.

A 35-year-old female, height 65 inches, weight 60kg, with severe asthma is on AC/VC. Current settings: Vt: 350, f: 18, FiO2: 0.50, PEEP: +5. ABG shows respiratory acidosis. What's the best adjustment?

a)

Increase tidal volume to 450mL

b)

Decrease PEEP to +3

c)

Increase respiratory rate to 22

d)

Reduce FiO2 to 0.45

12.

A 60-year-old male with COPD, height 68 inches, weight 75kg, is on AC/VC with Vt: 550, f: 16, FiO2: 0.40, PEEP: +6. Plateau pressure is 28cmH2O. Patient is spontaneously breathing 20 breaths/min. How should ventilation be increased?

a)

Increase tidal volume to 600mL

b)

Increase respiratory rate to 18

c)

Increase PEEP to +8

d)

Increase respiratory rate to 22

13.

A 40-year-old female with pneumonia, height 62 inches, weight 55kg, is on AC/VC. Current settings: Vt: 400, f: 20, FiO2: 0.60, PEEP: +10. Plateau pressure is 35cmH2O. What's the most appropriate action?

a)

Decrease PEEP to +8

b)

Increase FiO2 to 0.70

c)

Reduce tidal volume to 350mL

d)

Increase respiratory rate to 22

14.

A 55-year-old male with ARDS, height 72 inches, weight 90kg, is on AC/VC with Vt: 600, f: 24, FiO2: 0.80, PEEP: +14. ABG shows respiratory alkalosis. What's the best adjustment?

a)

Increase tidal volume to 550mL

b)

Decrease respiratory rate to 22

c)

Increase PEEP to +16

d)

Reduce tidal volume to 450mL

15.

A 45-year-old female with bronchiectasis, height 64 inches, weight 70kg, 2 days post-operative, is on AC/VC. Current settings: Vt: 450, f: 18, FiO2: 0.40, PEEP: +5. Plateau pressure is 24cmH2O. ABG results: ph: 7.36, PaCO2: 62, PaO2: 67, HCO3: 34. What's the most appropriate action?

a)

Maintain current settings

b)

Decrease tidal volume to 400mL

c)

Spontaneous breathing trial

d)

Increase FiO2 to 0.60

16.

A 65-year-old male with pulmonary edema, height 69 inches, weight 80kg, is on AC/VC with Vt: 600, f: 20, FiO2: 0.60, PEEP: +10. Plateau pressure is 33cmH2O. What's the most appropriate action?

a)

Increase PEEP to +12

b)

Decrease respiratory rate to 18

c)

Reduce tidal volume to 500mL

d)

Increase FiO2 to 0.70

17.

A 30-year-old female with status asthmaticus, height 66 inches, weight 65kg, is on AC/VC. Current settings: Vt: 350, f: 22, FiO2: 0.50, PEEP: +5. ABG shows severe respiratory acidosis. What's the most appropriate action?

a)

Increase tidal volume to 400mL

b)

Increase respiratory rate to 26

c)

Increase PEEP to +7

d)

Decrease FiO2 to 0.45

18.

A 70-year-old male with COPD exacerbation, height 68 inches, weight 85kg, is on AC/VC with Vt: 650, f: 14, FiO2: 0.35, PEEP: +5. Plateau pressure is 25cmH2O. ABG shows partially compensated respiratory acidosis. What's the best action?

a)

Increase tidal volume to 700mL

b)

Increase set rate to 18

c)

Reduce tidal volume to 550mL

d)

Maintain current settings

19.

A 50-year-old female with ARDS, height 63 inches, weight 58kg, is on AC/VC. Current settings: Vt: 300, f: 26, FiO2: 0.90, PEEP: +16. ABG shows hypoxemia. What's the most appropriate adjustment?

a)

Increase tidal volume to 350mL

b)

Decrease PEEP to +14

c)

Increase respiratory rate to 28

d)

Increase PEEP to +18cmH20

20.

What is the normal Vd/VT ratio?

a)

0.4-0.6

b)

0.2-0.4

c)

0.6-0.8

d)

0.8-1.0

21.

A patient with a traumatic brain injury is being mechanically ventilated. The current ventilator settings are: AC/VC, f: 18, Vt:450, FiO2: 0.5, PEEP: +5. An ABG is obtained with the following results: pH: 7.50, PaCO2: 30, PaO2: 92, HCO3: 25.

Which ventilator settings would achieve a PaCO2 of 40?

a)

Vt: 500, f: 16

b)

Vt: 420, f: 10

c)

Vt: 380, f: 16

d)

Vt: 330, f: 12

22.

A patient with admitted for blunt chest wall trauma is being mechanically ventilated. The current ventilator settings are: AC/VC, f: 14, Vt:400, FiO2: 0.6, PEEP: +10. An ABG is obtained with the following results: pH: 7.25, PaCO2: 52, PaO2: 86, HCO3: 23.

Which ventilator settings would achieve a PaCO2 of 45?

a)

Vt: 500, f: 13

b)

Vt: 420, f: 21

c)

Vt: 480: f: 17

d)

Vt: 650, f: 11

23.

A patient admitted for blunt chest wall trauma is being mechanically ventilated. The current ventilator settings are: AC/VC, f: 14, Vt:400, FiO2: 0.6, PEEP: +10. An ABG is obtained with the following results: pH: 7.25, PaCO2: 52, PaO2: 86, HCO3: 23.

Which ventilator settings would achieve a PaCO2 of 45?

a)

Vt: 500, f: 13

b)

Vt: 420, f: 21

c)

Vt: 480: f: 17

d)

Vt: 650, f: 11

24.

A patient admitted for CHF exacerbation is being mechanically ventilated. The current ventilator settings are: AC/VC, f: 14, Vt:400, FiO2: 0.6, PEEP: +10. An ABG is obtained with the following results: pH: 7.25, PaCO2: 52, PaO2: 86, HCO3: 23.

What would the set rate have to be changed to in order to achieve a PaCO2 of 40?

a)

18

b)

16

c)

20

d)

22

25.

A patient admitted for altered mental status is being mechanically ventilated. The current ventilator settings are: AC/VC, f: 17, Vt: 625, FiO2: 0.4, PEEP: +8. An ABG is obtained with the following results: pH: 7.59, PaCO2: 26, PaO2: 82, HCO3: 25.

What would the tidal volume have to be changed to in order to achieve a PaCO2 of 35?

a)

460 mL

b)

520 mL

c)

420 mL

d)

560 mL

26.

A female patient (68-kg IBW) is being ventilated with PC-CMV, f = 14/min, PIP = 18 cm H2O, TI = 1.0 s, TE = 3.0 sec. The flow scalar is noted to be returning to baseline. The patient’s measured VT is 680 mL. ABG results on these settings are: pH 7.51, PaCO2 29 mm Hg, HCO3- 24 mEq/L.

The most appropriate action to take is which of the following?

a)

Increase the flow

b)

Decrease the tidal volume

c)

Decrease the rate

d)

Increase the Ti

27.

A male patient (67-kg IBW) is intubated and ventilated with PC-CMV, f = 18/min, set PIP = 22 cm H2O, resulting in a VT of 500 mL.

The ABG results on this setting are: pH 7.35, PaCO2 45 mm Hg, and HCO3- 23 mEq/L. Later that day on the same settings, the ABG results are: pH 7.29, PaCO2 52 mm Hg, and  HCO3- 23 mEq/L with an exhaled VT of 320 mL.

The most appropriate action at this time is which of the following?

a)

Increase PIP

b)

Decrease PIP

c)

Increase Set Rate

d)

Decrease Set Rate
