RAD 117 Final Exam

Total questions: 18

Worksheet time: 9mins

Name
Class
Date
1.

The shoulder joint is formed between the head of the humerus and the ________.

a)

Glenoid fossa of the scapula

b)

Coracoid process of the scapula

c)


Acromion process of the scapula

d)

Glenoid fossa of the clavicle

2.

The lateral extremity of the clavicle articulates with the:

a)

Sternum

b)

Acromion

c)

Coracoid

d)

Xiphoid

3.

The _____ is found at the proximal end of the metacarpals.

a)

Base

b)

Head

c)

Body

d)

Tuberosity

4.

Which projection is this?

a)

AP shoulder internal rotation

b)


AP shoulder neutral rotation

c)

AP shoulder external rotation

d)

Inferosuperior axial shoulder

5.

The correct CR entrance point for the fan lateral hand is the:

a)

1st MCP joint

b)

2nd MCP joint

c)

3rd MCP joint

d)

PIP joint

6.

The "cotton wool" appearance of radiographs is most often caused by:

a)

Osteomyelitis

b)

Marble bone

c)

Paget disease

d)

Osteogenic sarcoma

7.

Which of these methods will best demonstrate the carpal tunnel?

a)

Modified Stecher

b)

Gaynor Hart

c)

Lawrence

d)

Neer

8.

A true AP of the proximal humerus requires the shoulder to be in ________ position.

a)

Neutral

b)


Internal rotation

c)

Abduction

d)

External rotation

9.

Which joint is letter R?

a)

5th MCP joint

b)

5th CMC joint

c)

5th DIP joint

d)

5th PIP joint

10.

The two projections of the clavicle are the _______ and ________.

a)

AP and lateral

b)

PA and PA axial

c)

AP and oblique

d)

AP and AP axial

11.

What is the term for the anterior surface of the scapula?

a)


Costal surface

b)

Dorsal surface

c)

Scapular surface

d)

Supraspinous surface

12.

The head of the radius is located at the ____ end of the radius.

a)

Proximal

b)

Distal

c)

Medial

d)

Lateral

13.

Letter F is the:

a)

Triquetrum

b)

Scaphoid

c)

Hamate

d)

Trapezoid

14.

The joint located between the distal phalanx and the middle phalanx is the:

a)

Carpometacarpal joint

b)

Metacarpophalangeal joint

c)

Distal interphalangeal joint

d)

Proximal interphalangeal joint

15.

Which of these pathologies would be benign?

a)

Osteochondroma

b)

Chondrosarcoma

c)

Multiple myeloma

d)

Bone metastasis

16.

Letter B is the:

a)

Acromion

b)

Coracoid process

c)

Coronoid process

d)

Glenoid fossa

17.

The CR for the inferosuperior axial shoulder should be:

a)

Angled 25-30 degrees medially

b)

Placed at the acromioclavicular joint

c)

Angled 25-30 degrees laterally

d)

Angled 10-15 degrees inferior

18.

The modified Stecher method can be performed with the hand elevated in a neutral position or in ulnar deviation.

a)

True

b)

False
