Pretrip School Bus

Match

Match for Dash Gauge Readings:

• 35-75

• 120-140

• when below 50% report to mechanic

• 165-185

• 12-16

Oil Pressure Gauge

Air Pressure Gauge

DEF Gauge

Transmission Temperature

Voltmeter reading for the battery volts

• Oil Pressure Gauge

• Air Pressure Gauge

• DEF Gauge

• Transmission Temperature

• Voltmeter reading for the battery volts

Match

Match the following

• Left Front Compartment

• Middle front Compartment

• Right Front Compartment

• Checked with engine off

• checked with engine on

air pressure valve

radiator and coolant reservoir

Power Steering Reservoir

engine oil

transmission fluit

• air pressure valve

• radiator and coolant reservoir

• Power Steering Reservoir

• engine oil

• transmission fluit

Multiple Choice

Which of these is the range for the battery amp gauge?

• 35-75

• 120-140

• when below 50% report to mechanic

• 165-185

• 12-16

Multiple Choice

Which of these in the Dash Indicator Lights and Gauges section would be your response about the DEF gauge?

• 35-75

• 120-140

• when below 50% report to mechanic

• 165-185

• 12-16

Multiple Choice

Which of these numbers in the Dash Indicator Lights and Gauges test will match your response to the oil pressure gauge?

• 35-75

• 120-140

• when below 50% report to mechanic

• 165-185

• 12-16

Multiple Choice

Which of these numbers in the Dash Indicator Lights and Gauges test will match your response to the temperature gauge?

• 35-75

• 120-140

• when below 50% report to mechanic

• 165-185

• 12-16

Multiple Choice

Which of these numbers in the Dash Indicator Lights and Gauges test will match your response to the air pressure gauge?

• 35-75

• 120-140

• when below 50% report to mechanic

• 165-185

• 12-16

Fill in the Blanks

Fill in the Blanks

Fill in the Blanks

Fill in the Blanks

Fill in the Blanks

Draw

_{Be able to locate or comment about:}

_{^{1-Overall Appearance}}

_{^{2-Engine Oil}}

_{^{3-Power Steering Pump}}

_{^{4-Transmission Fluid}}

_{^{5-Air Compressor}}

_{^{6-Serpentine Belt}}

_{^{7-water pump and alternator}}

_{^{8-Hoses, lines, clamps}}

Fill in the Blanks

Fill in the Blanks

Drag and Drop

Which section of Front Wheel/Rim repeats this phrase:

   ​ ​" No Missing Parts  /  All threads are the same depth”

​

Placeholder

Drag these tiles and drop them in the correct blank above

Hub Bolts

Hub Seal

Wheel

front axle

Lug Nuts, Bolts, and Holes

Multiple Choice

1. Which section of Front Wheel Brake System repeats this phrase:

2. “No Cracks  /  No Welds  /  No Damage”

• Air Hose Lines & Couplings

• 1. Brake Chamber & Clamp

• 1. Slack Adjusters & Push Rods

• 1. Brake

  2. Drums

• Brake

  Lining

Multiple Choice

1. Which section of Front Wheel Brake System repeats this phrase:

2. “At 90° angle  /  Should not move more than 1”

3. (with brakes released) when pulled by hand

• Air Hose Lines & Couplings

• 1. Brake Chamber & Clamp

• 1. Slack Adjusters & Push Rods

• 1. Brake

  2. Drums

• Brake

  Lining

Multiple Choice

1. Which section of Front Wheel Brake System repeats this phrase:

   1. “No Damage  /  No Leaks  /  No Dry Rot  /  Secure to Bus”

• Air Hose Lines & Couplings

• 1. Brake Chamber & Clamp

• 1. Slack Adjusters & Push Rods

• 1. Brake

  2. Drums

• Brake

  Lining

Multiple Choice

1. Which section of Front Wheel Brake System repeats this phrase:

2. “Not worn dangerously thin  /  No oil or grease visible”

• Air Hose Lines & Couplings

• 1. Brake Chamber & Clamp

• 1. Slack Adjusters & Push Rods

• 1. Brake

  2. Drums

• Brake

  Lining

Drag and Drop

Which section of Front Wheel/Rim repeats this phrase:

   ​ ​

Placeholder

“No Cracks  /  No Welds  /  No Damage  /  Secure to the Bus”

Drag these tiles and drop them in the correct blank above

Lug Nuts, Bolts, and Holes

Hub Bolts

Hub Seal

Wheel

Front Axle

Multiple Choice

Which section of "Front Wheel Tires" must repeat this phrase:

“Inflated to manufacturer’s specs  /  Checked with gauge  /

Valve Stem and cap Present"

• Inflation

• Splash/Mud Guards

• Tire Depth

Multiple Choice

Which section of "Front Wheel Tires" must repeat this phrase:

“No Damage  /  Secure to Bus”

• Inflation

• Splash/Mud Guards

• Tire Depth

Multiple Choice

1. 1. Which section of "Front Wheel Tires" must repeat this phrase:

   2. “4/32 inch minimum / Evenly worn  /  No Recaps  /  No Bulges  /  No Cuts  /  No Dry Rot”

• Inflation

• Splash/Mud Guards

• Tread

Multiple Choice

1. Which section of Front Wheel Brake System repeats this phrase:

2. “No Damage  /  No Leaks  /  Secure to the Bus”

• Brake Chamber & Clamp

• 1. Slack Adjusters & Push Rods

• Brake

  Drums

• Brake

  Lining

• Air Hose Lines and Couplings

Drag and Drop

Which section of Front Wheel/Rim repeats this phrase:

"No Damage / No Missing Parts / Secure to the Bus”​

​

Placeholder

​

Drag these tiles and drop them in the correct blank above

Lug Nuts, Bolts, and Holes

Hub Bolts

Hub Seal

Wheel

Front Axle

Drag and Drop

Which section of Front Wheel/Rim repeats this phrase:

“No Cracks  /  No Rust  /  All are tight and secure”

​

Placeholder

Drag these tiles and drop them in the correct blank above

Hub Seal

Wheel

Front Axle

Lug Nuts, Bolts, and Holes

Hub Bolts
