hvac

Open Ended

What could happen if refrigerant oil containers are not kept clean and dry during air-conditioning service?

Multiple Choice

Why is it important to follow service precautions when working with automotive air-conditioning systems?

• To ensure safety and prevent contamination

• To save time during repairs

• To reduce the cost of tools

• To avoid using refrigerant oil

Multiple Choice

Which of the following is NOT a recommended refrigerant safety precaution?

• Work in a well-ventilated area

• Wear protective gloves and clothing

• Use compressed air to leak test a R-134a system

• Never use compressed air to leak test a R-134a system

Multiple Choice

Why is it important never to mix R-12 and R-134a refrigerants, components, or equipment?

• It can cause equipment malfunction and safety hazards

• It increases system efficiency

• It reduces the risk of frostbite

• It improves cooling performance

Open Ended

List two special precautions that should be taken when servicing the A/C system in hybrid vehicles.

Multiple Choice

Which of the following are signs of potential issues during initial system checks?

• Oil leakage

• Unusual smells and noises

• Condenser damage or debris

• All of the above

Multiple Choice

Which of the following is NOT a simple check to perform on an automotive air conditioning system?

• Check vent outlet temperatures

• Check blower speeds

• Check oil level in the engine

• Check the sight glass if equipped

Multiple Select

Which of the following are likely features of automatic climate control systems according to the trouble codes slide?

• Self-diagnostic capability

• Manual operation only

• Ability to display codes and data

• No electronic components

Open Ended

Describe the steps involved in using a scan tool to retrieve diagnostic information from the body control module (BCM).

Open Ended

Explain how both noise and odor issues can be diagnosed in an automotive HVAC system, referencing the types of noises and odors listed.

Multiple Choice

What is the primary purpose of a manifold gauge set in performance testing of an automotive air conditioning system?

• To measure oil pressure

• To connect electrical circuits

• To measure refrigerant pressures

• To clean the air filter

Multiple Choice

Which of the following statements best describes the difference between the service valves of the R-134a and R-1234yf systems?

• The R-134a system uses a threaded valve, while the R-1234yf system uses a quick-connect valve.

• Both systems use the same type of service valve.

• The R-1234yf system uses a threaded valve, while the R-134a system uses a quick-connect valve.

• Both systems use threaded valves but with different diameters.

Open Ended

Explain the importance of measuring outlet temperature in an automotive air conditioning system.

Multiple Select

Which of the following are reasons for performing a purity test on an automotive air conditioning system?

• To identify unknown system contents

• To prevent damage from combustible agents

• To sample refrigerant contents

• To increase system pressure

Open Ended

List the steps involved in connecting a gauge set to an automotive air conditioning system.

Multiple Choice

When performing testing procedures on an automotive A/C system, why is it important to refer to the manufacturer's temperature and pressure charts?

• To ensure accurate diagnosis and system performance

• To avoid overcharging the system

• To reduce engine speed

• To increase refrigerant flow

Open Ended

Compare the pressure readings for CFC-12 and HFC-134a at 40°F (4.4°C). What does this tell you about the two refrigerants?

Multiple Choice

Which of the following could be a cause of high-side pressure being higher than normal during performance testing of an automotive HVAC system?

• Air in the system

• Low refrigerant

• Defective compressor

• Poor airflow across the evaporator

Multiple Select

What are possible causes for low-side pressure being lower than normal in an automotive HVAC system?

• Faulty metering device

• Poor airflow across the evaporator

• Restriction in the low side

• Refrigerant undercharge

Multiple Choice

A HVAC system does not cool and has low low-side and low high-side pressures. Technician A says the system is undercharged. Technician B says the condenser is probably blocked. Who is correct?

• Only Technician A

• Only Technician B

• Both Technician A and B

• Neither Technician A nor B

Open Ended

Explain how leaks can affect pressure readings in an automotive HVAC system and describe at least two methods for detecting leaks.

Open Ended

Reflecting on today's lesson about air-conditioning diagnosis and service, what is one important precaution you will remember when servicing an air-conditioning system?

Multiple Choice

Which of the following is NOT a recommended service precaution when working with automotive air-conditioning systems?

• Wipe away any oil or dirt before disconnecting a connection

• Keep tools clean and dry

• Leave a system open for as long as possible

• Evacuate a system any time it has been opened
