Sketching and Dimensioning Key Terms

Sketching and Dimensioning Key Terms

Assessment

Quiz

Life Skills

8th Grade

Hard

Created by

Frasier Dew

Used 16+ times

FREE Resource

AI

Enhance your content

Add similar questions
Adjust reading levels
Convert to real-world scenario
Translate activity
More...

20 questions

Show all answers

1.

MULTIPLE CHOICE QUESTION

45 sec • 1 pt

Explanatory notes added to a drawing.

Extension Line

Annotation

Plane

Sketch

2.

MULTIPLE CHOICE QUESTION

30 sec • 1 pt

A line type that is used to indicate the axis of symmetry for a part or feature.

Hidden Line

Object Line

Centerline

Construction Line

3.

MULTIPLE CHOICE QUESTION

30 sec • 1 pt

Thin lines that serve as guides while sketching or drawing.

Hidden Line

Object Line

Centerline

Construction Line

4.

MULTIPLE CHOICE QUESTION

30 sec • 1 pt

The distance from front to back.

Depth

Width

Height

5.

MULTIPLE CHOICE QUESTION

30 sec • 1 pt

A straight line passing from side to side through the center of a circle or sphere.

Diameter

Radius

Plane

Scale

6.

MULTIPLE CHOICE QUESTION

30 sec • 1 pt

A measurable extent, such as the three principal dimensions of an object of width, height, and depth.

Annontation

Dimension

Thumbnail

Perspective

7.

MULTIPLE CHOICE QUESTION

30 sec • 1 pt

Thin lines capped with arrowheads, which may be broken along their length to provide space for the dimension numerals.

Dimension

Isometric

Dimension Line

Object Line
