WorksheetsArduino Basic Components and their functions
Total questions: 36
Worksheet time: 18mins
What is an Arduino?
A desktop computer
A computer chip
A micro controller
A PlayStation controller
The long leg of the LED (Anode) must be connected to:
The signal
The ground
Any cable
The resistor
None of the options are correct
What is Arduino primarily used for?
Gardening
Cooking
Painting
Electronic Creations
What do you need to complete an Arduino project?
A computer and a camera
A tablet and a camera
A computer and an Uno board
A phone and a tablet
Long end of an LED is
+ (Positive)
- (Negative)
What is the primary language used for programming in Arduino?
Python
C++
Java
JavaScript
Which PIN is the LED connected to in this picture?
Digital Pin 2
Digital Pin 4
Digital Pin 1
Analog Pin 0
We want to turn on the built-in LED of the Arduino board, What pin and configuration do we use?
pin 11 as an INPUT
pin 13 as an OUTPUT
pin 3 as an OUTPUT
pin BUILT as an OUTPUT
pin 13 as an INPUT
The negative terminal of a circuit
5V
3.3V
GND
Reset
TX<-1
How many Digital In/Out pins are there on an ARDUINO UNO?
6
13
12
14
What is the difference between ANALOG signals and DIGITAL signals?
Digital signals are electric, Analog signals are mechanical
Analog signals are an older form of tech that has been replaced by digital
Digital signals can have any value within the range of 0 -255
Analog signals vary between 0 and 100%, while Digital signals can be either 0 or 100%.
Identify this component
Arduino Uno board
Raspberry Pi
Breadboard / Projectboard
White Plastic Board
What is Arduino?
A company for selling microcontrollers
A software used to program microcontrollers
An open-source electronics prototyping platform based on flexible, easy-to-use hardware and software
Arduino can interact with...
buttons, leds
smartphone
sensors
all of the above
Temperature being displayed
What is the main purpose of the Arduino's digital pins?
To connect to the internet
To power the board
To read and write digital signals
To store data
What is the function of the Arduino's analog pins?
To play music
To read analog signals
To display images
To connect to a monitor
Which of the following is a common use for an Arduino?
Making a sandwich
Controlling a robot
Writing a book
Painting a picture
mBlock is a software for...
coding Lego projects
text editing
block-based coding
image editing
Robotic is
Sector dedicated to the design and construction of robots
The product of the robotics field
Humanoid Robots
Arduino Braccio Robotic Arm.
What is a robot?
Programable Machine
Design robot
Construct robot
Is a open source programable device.
For a robot to be functional, What should it have? Select 2.
Wheel
Sensors
Arms
Actuators
Select two primary components of robot.
Arm
Micro-controllers
Sensor
Python
Select two examples of Arduino
Lego H/3000
Arduino uno
Arduino Nano
Ultrasonic Arduino Sensors
Select two programming languages used for arduino.
HTML
C++
Mblock
Java
What is a device that measures or detects a real-world condition of the robot?
Board
Microcontroller
Sensor
Thermometer
What can a sensor measure? Select two.
Temperature
Grades
Distance
Quantity
Which language style you are using to program Arduino board?
Text Based
High Level Language
Block Based Coding
Voice Based
What is this component called?
Motor driver
Screw drive
Sensor
Motor
What is this part called?
Wire
Programming cable
Charging cable
Ethernet wire
What is this part called?
Distance sensor
IR sensor
Noise sensor
Remote
What is this part called?
IR sensor
Bluetooth module
Arduino board
Chip
What is this part called?
Servo motor
Medium motor
DC geared motor
Sensor
What is this part called?
Servo motor
Microcontroller
Arm
DC geared motor
What is the brown part called in a Robot?
Robot chasis
Board
Main body
Floor
