Basic Mechanics Tool ID #1

Total questions: 37

Worksheet time: 2hrs 14mins

Name

Class

Date

1.

a)

Gear Puller

b)

Snap Ring Pliers

c)

Torque Wrench

d)

Slip Joint Pliers

2.

a)

Flywheel Strap Wrench

b)

Ratchet wrench

c)

Oil filter Wrench

d)

Torque Wrench

3.

a)

Compression Tester

b)

Torque Wrench

c)

Piston Ring Expander

d)

Piston Ring Compressor

4.

a)

Flywheel puller

b)

Torque Wrench

c)

Flywheel Strap Wrench

d)

Fuel Line Removal tool

5.

a)

Snap Ring Pliers

b)

Valve Spring Compressor

c)

Ignition Tester

d)

Spark Plug Socket

6.

a)

Chipping hammer

b)

Ball-Peen Hammer

c)

Sledge Hammer

d)

Square hammer

7.

Name the tool

a)

Hammer

b)

Air compressor

c)

Slip Joint pliers

d)

Locking pliers

8.

Name the tools.

a)

Lets go Nuts driver

b)

Stubby Screwdriver

c)

Standard Screwdriver

d)

Nut Driver

9.

a)

Slotted Screwdriver

b)

Phillips Screwdriver

c)

Torx Head Screwdriver

d)

Screwdriver Bit

10.

Name the tool.

a)

Irwin

b)

Phillips head bit

c)

X Bit

d)

Square Recces Screwdriver

11.

Identify the following Part

a)

Tappet

b)

Pushrods

c)

Cam Lobes

d)

Valves

12.

Identify the following Part

a)

Counter Weight

b)

Spark Timer

c)

Magnet Wheel

d)

Flywheel

13.

Identify the following Part

a)

Retaining Rings

b)

Snap Rings

c)

Piston Rings

d)

Compression Rings

14.

Identify the following Part

a)

Closed End Wrench

b)

Open End Wrench

c)

Combination Wrench

d)

Box Wrench

15.

Identify the following Part

a)

Circle End Wrench

b)

Open End Wrench

c)

Simple End Wrench

d)

Box End Wrench

16.

Identify the following Part

a)

Circle End Wrench

b)

Open End Wrench

c)

Combination Wrench

d)

Box End Wrench

17.

Identify the following Part

a)

Wire Feeler Gauge

b)

Metal Fan

c)

Feeler Gauge

d)

Valve Gapper

18.

Name the following Striking/Driving Tool.

a)

Ball Peen Hamer

b)

Mechanic Hammer

c)

Soft Faced Hammer

d)

Carpenter Hammer

19.

Name the following Fastening Tool.

a)

Phillips Screwdriver

b)

Offset Screwdriver

c)

Trox Screwdriver

d)

Standard Screwdriver

20.

Name the following Fastening Tool.

a)

Cresent Wrench

b)

Twist Wrench

c)

Open end Wrench

d)

Adjustable Wrench

21.

Name the following Cutting Tool.

a)

Pry Punch

b)

Hot Chisel

c)

Cold Chisel

d)

Cutting Punch

22.

Identify this tool.

a)

Claw Hammer

b)

Ball Pein Hammer

c)

Common Nail

d)

Fence Pliers

23.

Identify this tool.

a)

Pipe Wrench

b)

Combination Wrench

c)

Open End Wrench

d)

Box End Wrench

24.

a)

Tin snips

b)

side cutters

c)

rainbow pliers

d)

metal sheers

25.

a)

phillips screwdriver

b)

standard screwdriver

c)

flat pry drivers

d)

flat screwdriver

26.

a)

silver locking grips

b)

locking cutters

c)

vice grip locking pliers

d)

finger pinchers

27.

a)

impact socket

b)

impact wrench

c)

impact wrestling

d)

impact driver

28.

a)

come loose bar

b)

breaker machine

c)

breaker bar

d)

socket wrench

29.

a)

Ball Peen Hammer

b)

Wrench

c)

Claw Hammer

30.

a)

G Clamp

b)

C Clamp

c)

Bar clamp

31.

Identify the following Part

a)

Connecting Rod

b)

Camshaft

c)

Crankshaft

d)

Tappet

32.

Identify the following Part

a)

Connecting Rod

b)

Camshaft

c)

Crankshaft

d)

Tappet

33.

Identify the following Part

a)

Tappet

b)

Pushrods

c)

Cam Lobes

d)

Valves

34.

Identify the following Part

a)

Tappet

b)

Pushrods

c)

Cam Lobes

d)

Valves

35.

Identify the following Part

a)

Leak Down Tester

b)

Compression Tester

c)

Fuel Pressure Regulator

d)

Injector Tester

36.

Identify the following Part

a)

Variable Pick Tool

b)

Transitional Hole Cleaner

c)

Sparkplug Cleaner

d)

Wire Type Feeler Gauge

37.

Identify the following Part

a)

Inside Micrometer

b)

Outside Micrometer

c)

Dial Caliper

d)

C Clamp
