While performing a scheduled maintenance test drive, which of the following noises would LEAST LIKELY be scheduled for repair?

Which type of replacement drive belt is shown in the illustration described as a single continuous belt routed over multiple pulleys on an automotive accessory drive?

It's a good idea to routinely replace cooling system hoses:

Engine coolant can be tested by using any of the following EXCEPT a(an):

Which of the following should illuminate if the charging system is not working?

A vehicle's air filter is found to be contaminated with engine oil. Which of the following is the most likely cause?

When installing replacement spark plugs, some manufacturers recommend coating the threads with:

A pre-formed plastic pipe for the EVAP system is found to be cracked. Technician A says to wrap electrical tape around the crack to repair the leak. Technician B says to apply non-hardening sealant to the pipe. Who is correct?

An automatic transmission pan has been removed and is being reinstalled. Technician A says that some OEMs recommend using ATV sealant instead of a gasket. Technician B says that some OEMs recommend reusing the original gasket. Who is correct?

A CV joint boot is found to have a small split. Which of the following should be done?

A transmission cooler has developed a leak. Technician A says the cooler may be reliably repaired with epoxy. Technician B says the cooler may be reliably repaired with ATV sealant. Who is correct?

Technician A says that some automatic transmission filters are made of pleated paper. Technician B says that some transmission filters require removal of the transmission pan for replacement. Who is correct?

An oil-soaked engine mount:

A manual RWD transmission is leaking at the rear seal. Technician A says the transmission will have to be removed from the vehicle. Technician B says that the drive shaft will have to be removed from the vehicle. Who is correct?

A drive shaft center support bearing is found to be rusty. The bearing should be:

When replacing the gear lube in a differential, be sure to do all of the following EXCEPT:

A vehicle owner complains that it is difficult to get a 4WD vehicle into and out of 4WD. Which of the following is the most likely cause?

After having a tire replaced on a vehicle, a customer complains that the ABS light stays ON. Which of the following is the most likely cause?

Technician A says that Supplemental Restraint System (SRS) electrical connectors are often yellow in color. Technician B says that SRS circuits must be allowed to power down for 10 seconds. Who is correct?

A power steering pump is being replaced on a vehicle. Technician A says all the power steering hoses should also be replaced. Technician B says, depending on the system, the power steering filter should be cleaned or replaced. Who is correct?

Technician A says that if a strut rod bushing has deteriorated, it is easier to replace the entire strut rod. Technician B says that strut rods themselves seldom fail. Who is correct?

Which of the following parts, as shown in the illustration, is being inspected for wear?

When driving slowly over irregular surfaces, a clunking noise is heard from the front end of a vehicle. Technician A says that the vehicle's sway bar bushings may be faulty. Technician B says that the coil springs may be weak. Who is correct?

A vehicle is experiencing excessive rear-end sway on turns. Which of the following is the most likely cause?

Technician A says that a faulty rear ball joint could affect a vehicle's rear wheel alignment. Technician B says that a faulty rear ball joint could be a safety hazard. Who is correct?

A mist of oil is seen on the tubes of a vehicle's rear shock absorbers. The shocks:

With the steering wheel straight, a vehicle tends to drift to the left while travelling on a level road. Technician A says that the air pressure in the vehicle's right front tire may be low. Technician B says that the vehicle may need a wheel alignment. Who is correct?

When a vehicle is being test driven straight on a level road, the steering wheel is not centered. Which of the following is the most likely cause?

A vehicle experiences "dog tracking." Which of the following is the most likely cause?

When driven at very slow speeds, a vehicle's steering wheel tends to shimmy. Which of the following is the most likely cause?

Technician A says that it's OK to repair a tire when two puncture repairs overlap each other. Technician B says when two tire punctures are within several inches of each other and on the same tread line, the tire should be scrapped. Who is correct?

During a test drive, a high-pitched metallic scraping noise is heard whenever a vehicle turns a corner. Which of these is the most likely cause?

A vehicle's red brake warning light stays on whenever the ignition is ON and the engine is running. Any of the following could be the cause EXCEPT:

Technician A says it's a good idea to open a caliper bleed screw before retracting the caliper piston. Technician B says to start brake bleeding at the wheel closest to the master cylinder. Who is correct?

Technician A says that whenever drum brake shoes are being replaced, the drum brake hardware should be cleaned in a parts washer and re-used. Technician B says that when installing duo-servo brakes, the larger of the two shoes should be installed towards the front of the vehicle. Who is correct?

A vehicle's parking brake should be adjusted:

Technician A says that some disc brake pistons may be retracted using a "C" clamp. Technician B says that some caliper pistons may be retracted using a special retracting tool. Who is correct?

Upon removal of a vehicle's left-front brake pads, one pad in the floating-type caliper is worn much farther than the other. Which of the following is the most likely cause?

Which of the following is used to check for rotor runout?

When refilling a brake master cylinder, always use:

A vehicle that uses the same hydraulic pressure pump for both the power brakes and power steering has a:

Technician A says that current can be measured in a live circuit by connecting an ammeter in parallel across a load. Technician B says that current can be measured in a non-live (dead) circuit by using an amp’s clamp. Who is correct?

As shown in the illustration, a fuse is being checked for continuity with a digital multimeter (DMM). In this case, the fuse:

A battery load test is being performed. The proper method is to:

A load test is being performed on a vehicle's charging system. Technician A says it's OK to increase the load until the charging system voltage just starts to drop, then take note of the amperage. Technician B says it's OK to apply a load until the alternator light comes on, then take note of the amperage. Who is correct?

The puller shown above is used to remove a (an):

A headlight alignment procedure is being performed. Which of the following is LEAST LIKELY to cause the alignment to be incorrect?

Technician A says that the brake warning light on the instrument panel cluster dash is a yellow light. Technician B says that the ABS indicator light on the IPC is red. Who is correct?
