Non Metallic Eng Materials-Polymer

Multiple Choice

Which of the following is a NATURAL POLYMER?

• Rubber (latex)

• Polystyrene

• Polyethylene

• Nylon

Multiple Select

Which of the following is a SYNTHETIC POLYMER?

• cellulose

• latex

• polyethylene

• polystyrene

Multiple Select

Which of the following statements about homopolymers and copolymers is/are correct?

• Homopolymers are made from one type of monomer.

• Copolymers are made from two or more types of monomers.

• Homopolymers have a non-uniform structure.

• Copolymers are made from a single type of monomer.

Multiple Choice

Which type of copolymer has monomers arranged in a regular alternating pattern?

• Random Copolymer

• Block Copolymer

• Alternating Copolymer

• Graft Copolymer

Multiple Choice

Which of the following are examples of block copolymers?

• Polystyrene-b-Polybutadiene

• Polyethylene

• Nylon-6,6

• High-Impact Polystyrene (HIPS)

Drag and Drop

In the ​ ​

Placeholder

stage, a reactive species is generated using an initiator.
In the propagation step, the active chain end continues to add ​

Placeholder

, extending the ​

Placeholder

.
In the ​

Placeholder

step, the chain growth stop when two active chain ​

Placeholder

.

Drag these tiles and drop them in the correct blank above

initiation

termination

combined

monomer

polymer chain

elastomer

latex

polystyrene

Multiple Select

Which aspects differentiate chain-growth polymerization from step-growth polymerization? Select all that apply.

• Reaction Mechanism

• Growth Pattern

• Molecular Weight Formation

• Reaction Speed

Multiple Choice

Which of the following is a correct classification of polymers based on their origin?

• Natural polymers and synthetic polymers

• Thermoplastics and thermosets

• Linear and branched polymers

• Elastomers and cross-linked polymers

Multiple Select

Which of the following are examples of natural polymers?

• Starch

• PVC

• Cellulose

• Nylon

Drag and Drop

​

Placeholder

consists of long, straight chain of monomers.

​

Placeholder

consists of chains with side branches.​
​

Placeholder

is the polymers with covalent bonds between chains, formimg a network.

Drag these tiles and drop them in the correct blank above

Linear polymers

Branched polymers

Cross-linked polymers

monomer

elastomer

Multiple Choice

Match the following types of polymers with their correct characteristics:
1. Thermoplastics 2. Thermosets 3. Elastomers.
A. Stretchable and return to original shape B. Harden permanently after shaping C. Soften when heated, harden when cooled

• 1-C, 2-B, 3-A

• 1-A, 2-B, 3-C

• 1-B, 2-C, 3-A

• 1-C, 2-A, 3-B

Open Ended

List two common applications for thermoplastics :

Multiple Select

Which of the following are limitations of thermosets? Select all that may apply:

• Non-recyclable due to permanent cross-linked structure

• Often brittle, limiting use in flexible applications

• Can be reshaped and remelted multiple times

• Low resistance to deformation under heat

Multiple Choice

Which of the following statements best describes the main difference between thermoplastics and thermosets?

• Thermoplastics can be reshaped multiple times, while thermosets cannot be reshaped after curing.

• Thermoplastics are always brittle, while thermosets are always flexible.

• Thermoplastics are non-recyclable, while thermosets are easily recyclable.

• Thermoplastics harden permanently upon heating, while thermosets soften when heated.

Multiple Choice

What define the characteristic of elastomers?

• They are hard and brittle at room temperature

• They can stretch significantly and return to original shape

• They dissolve easily in solvents

• They have high load-bearing capacity

Multiple Choice

Which of the following are applications of silicone rubber?

• Medical devices

• Automotive tires

• Footwear

• Packaging materials

Drag and Drop

​ ​

Placeholder

determine how a polymer behaves under physical forces, such as tension, compression, or bending.

​

Placeholder

​ determine how a polymer behaves when exposed to an electric field.

​

​

Placeholder

determine the polymer's resistance to environmental factors, chemicals, and solvents.

​

Placeholder

describe how polymers behave when exposed to heat or temperature changes.

​

Placeholder

determine how a polymer interacts with light.

Drag these tiles and drop them in the correct blank above

Mechanical Properties

Electrical Properties

Chemical Properties

Thermal Properties

Optical Properties

Multiple Choice

Which of the following is NOT an advantage of engineering polymers?

• Good mechanical and wear properties

• Chemical resistance

• Stable at moderate temperatures (100–250 °C)

• Highly brittle and easily fractured under load

Multiple Select

Which of the following are examples of engineering polymers? (Select all that apply)

• Polyethylene (PE)

• Polyether Ether Ketone (PEEK)

• Polystyrene (PS)

• Nylon (Polyamide)

Well done!
