3D Design Vocabulary Quiz

What are 2D sketching tools used for in 3D design vocabulary?

• Used to edit or measure lengths in OnShape

• Features that make flat (not 3D) shapes - rectangle, circle, etc

• Tool used to transfer 2D designs to 3D designs

• 3d surface where you begin your design

What does the term "extrude" refer to in 3D design?

• A straight line or plane that touches a curve or curved surface at a point, but if extended does not cross it at that point

• Features that make not flat (not 2D) shapes - extrude, revolve etc

• Rounded corner or transition between two surfaces in engineering and design

• tool used to transfer 2d designs to 3d

What is the definition of "perpendicular" in the context of 3D design?

• At an angle of 90° to a given line, plane, or surface

• Parallel to the plane of the horizon (left and right)

• Such that the top is directly above the bottom (up and down)

• Side by side and having the same distance continuously between them

What does "fillet" mean in engineering and design?

• The mathematical requirements placed on the geometric elements in a 3D solid model

• Circles, arcs, or other shapes which share the same center, the larger often completely surrounding the smaller

• Parallel to the plane of the horizon (left and right)

• Rounded corner or transition between two surfaces in engineering and design

when something is 'parallel'

• used to edit or measure

• 3d surface where you begin your design

• side by side having the same distance between them

• transfers from 2d to 3d

the term 'concentric"

• person who can focus really well

• circles or arcs which share the same center

• made from concentrate like orange juice

when something is 'horizontal'

• the object goes up and down

• the object goes left and right

what is the origin?

• 2 lines that are near each other but never touch

• what you click to close the sketch

• the point or place where something begins

in OnShape -- what is plane

• 3d surface where you begin your design

• tool used to extrude

• what you take to get to Florida

examples of 3d sketching tools include

• extrude / revolve

• dimension

• pulley

• spatula
