WorksheetsF4 Science Chapter 11 - Force and Motion
Total questions: 19
Worksheet time: 5hrs 45mins
Which of the following is scalar quantity (physical quantity with magnitide only) ?
Antara yang berikut, yang manakah kuantiti skalar (kuantiti fizik dengan magnitud sahaja)?
Distance
Jarak
Displacement
Sesaran
Velocity
Halaju
Acceleration
Pecutan
As shown in the diagram, a boy move from A to B then from B to C. What is his total displacement?
Seperti yang ditunjukkan di dalam gambar rajah, satu lelaki bergerak dari A ke B dan kemudian B ke C. Apakah jumlah sesarannya?
28 m
12 m
20 m
16 m
A man move toward East for 50m and then move West for 20m. The total time taken is 4 minutes. What is his average velocity?
Seorang lelaki bergerak menuju ke Timur sebanyak 50m dan kemudian bergerak ke Barat sebanyak 20m. Jumlah masa yang diambil ialah 4 minit. Apakah halaju puratanya?
17.5 ms-1
0.125 ms-1
7.5 ms-1
0.2917 ms-1
A car initially at rest accelerate to velocity of 20 ms-1 in 10s . Calculate the acceleration of the car.
Sebuah kereta dalam keadaan pegun memecut ke halaju 20 ms-1 dalam 10s. Hitungkan pecutan kereta itu.
200 ms-2
2 ms-2
2 ms-1
200 ms-1
Diagram shows the ticker tape of an object in motion. Which of the following statement correctly describe the motion of the object?
Rajah menunjukkan pita detik sesuatu objek dalam gerakan. Antara pernyataan yang berikut, yang manakah benar mengenai gerakan objek tersebut?
The object moves with uniform velocity
Objek itu bergerak dengan halaju seragam
The object is accelerating
Objek itu sedang memecut
The object is decelerating
Objek itu sedang menyahpecut
The object is at stationary
Objek dalam keadaan pegun
Diagram shows a ticker tape of a toy car sliding down a track. Calculate its acceleration.
Rajah menunjukkan satu pita detik kereta mainan meluncur menuruni landasan. Hitungkan pecutannya.
5 ms-2
500 ms-2
20 ms-2
15 ms-2
Calculate the deceleration of the object.
Hitungkan nyahpecutan objek tersebut.
15 ms-2
20 ms-2
10 ms-2
5 ms-2
Diagram shows a s-t graph of an object. What is the displacement of the object for the first 4s?
Rajah menunjukkan graf s-t sesuatu objek. Apakah sesaran objek itu pada 4s yang pertama?
4 m
6 m
2 m
0 m
Diagram shows a s-t graph of an object. What is the total displacement of the object?
Rajah menunjukkan graf s-t sesuatu objek. Apakah jumlah sesaran objek itu?
4 m
6 m
2 m
0 m
Diagram shows a s-t graph of an object. What is the velocity of of the object from t=7s to t-12s?
Rajah menunjukkan graf s-t sesuatu objek. Apakah halaju objek daripada t=7s hingga t=12s?
0 ms-1
-2 ms-1
2.2 ms-1
-2.2 ms-1
Based on the graph, calculate the total displacement.
Berdasarkan graf, hitungkan jumlah sesaran.
300 m
210 m
180 m
1000 m
Based on the graph, calculate the average velocity
Berdasarkan graf, hitungkan halaju purata.
8.4 ms-1
0 ms-1
7.4 ms-1
12 ms-1
Based on the graph, calculate the acceleration from t=0s to t=5s.
Berdasarkan graf, hitungkan pecutan daripada t=0s kepada t=5s.
2.4 ms-2
60 ms-2
30 ms-2
5 ms-2
Diagram shows v-t graph of an object. The object move in opposite direction from ___.
Rajah menunjukkan graf v-t sesuatu objek. Objek itu bergerak dalam arah bertentangan daripada ___.
6s ~ 8s
0s ~ 2s
The object always move in same direction
Objek sentiasa bergerak dalam arah yang sama
0s ~ 6s
Which of the following is correct about free fall?
Antara yang berikut, yang manakah benar mengenai jatuh bebas?
Free fall is affected by air resistance
Jatuh bebas dipengaruhi oleh rintangan udara
Object with different mass from the same location fall on the ground at different time
Objek dengan jisim yang berbeza dari lokasi yang sama jatuh ke tanah dalam masa yang berbeza
Fall with no acceleration
Jatuh tanpa pecutan
Takes place in vacuum only
Berlaku di vakum sahaja
No force acting on the object
Tiada daya yang dikenakan pada objek
Which graph represent the free fall of an object?
Graf yang manakah mewakili keadaan jatuh bebas sesuatu objek?
What is the phenomena shown in the diagram?
Apakah fenomena yang ditunjukkan di dalam gambar rajah?
Inertia
Inersia
Conservation of energy
Keabadian tenaga
Initiate
Inersit
Free fall
Jatuh bebas
Inertia is only affected by ___
Inersia hanya dipengaruhi oleh ___.
Mass of object
Jisim objek
Gravitational force
Daya graviti
Shape of the object
Bentuk objek
Size of the object
Saiz objek
Diagram shows two buckets X and Y, one filled with sand while the another one is empty. What is the observation when two buckets are swing simultaneously at the same height?
Rajah menunjukkan dua baldi X dan Y, satu berisi pasir manakala satu lagi kosong. Apakah pemerhatian apabila dua baldi dihayun secara serentak pada ketinggian yang sama?
X swings with higher speed
X berayun dengan kelajuan yang tinggi
X stops faster than Y
X berhenti dengan lebih cepat daripada Y
Y stops faster than X
Y berhenti dengan lebih cepat daripada X
X and Y stop at the same time
X dan Y berhenti pada masa yang sama
