Multiple Choice

What is the significance of orthographic projection in representing three-dimensional objects?

• It helps in coloring objects

• It allows accurate representation of 3D objects on 2D surfaces

• It is used for measuring the weight of objects

• It is only used in art

Open Ended

If you observe the simple objects in Figure 2.1 from different directions, what shapes do you think you will see?

Multiple Choice

Which of the following objects changes its shape when viewed from different directions?

• Cone

• Box

• Ball

• Bowl

Multiple Choice

Which of the following statements is true about the relationship between the object and its projection in image 2?

• The projection is always the same shape as the object.

• The projection depends on the direction of the rays.

• The projection is always larger than the object.

• The projection does not depend on the plane.

Open Ended

Explain how the projection (hình chiếu) of an object is formed on a plane, using the example in images 1 and 2.

Fill in the Blanks

Fill in the blank: The projection of an object on a plane is the image obtained after the object is

onto that plane.

Multiple Select

Select all correct statements about the characteristics of rays in the three types of projection shown in image 5.

• In orthogonal projection, rays are parallel and perpendicular to the plane.

• In parallel projection, rays are parallel to each other and to the projection direction.

• In central projection, rays converge at a single point.

• In parallel projection, rays are perpendicular to the plane.

Open Ended

Compare and contrast the three types of projection shown in images 5 and 6. What are the main differences in the behavior of the rays and the resulting images?

Multiple Choice

Which projection method is used to draw orthogonal projections?

• Parallel projection

• Central projection

• Orthogonal projection

• Oblique projection

Open Ended

Explain the position of the object in relation to each projection plane and the observer.

Fill in the Blanks

List the pairs of planes that are perpendicular to each other according to the diagram.

Multiple Choice

Which of the following is the correct direction for the side view projection?

• From the right

• From the left

• From above

• From below

Fill in the Blanks

The projection view labeled 'B' is placed

the projection view labeled 'A'.

Multiple Select

Select all correct statements about the arrangement of projection planes in the first angle method.

• The horizontal plane is below the vertical plane.

• The side plane is to the left of the vertical plane.

• The side plane is to the right of the vertical plane.

• The horizontal plane is above the vertical plane.

Multiple Choice

What is the position of the side view in orthogonal projection according to the lesson?

• It is placed to the left of the front view

• It is placed above the front view

• It is placed to the right of the front view

• It is placed below the front view

Multiple Choice

Hãy cho biết khối đa diện trong mỗi trường hợp ở Hình 2.7 được bao bởi các hình gì?

• Khối hình hộp chữ nhật được bao bởi các đa giác hình chữ nhật. Khối lăng trụ được bao bởi các đa giác hình chữ nhật và hình tam giác. Khối hình chóp được bao bởi các đa giác hình chữ nhật và hình tam giác.

• Khối hình hộp chữ nhật được bao bởi các đa giác hình vuông. Khối lăng trụ được bao bởi các đa giác hình vuông và hình tam giác. Khối hình chóp được bao bởi các đa giác hình vuông và hình tam giác.

• Khối hình hộp chữ nhật được bao bởi các đa giác hình chữ nhật. Khối lăng trụ được bao bởi các đa giác hình chữ nhật và hình tròn. Khối hình chóp được bao bởi các đa giác hình chữ nhật và hình tròn.

• Khối hình hộp chữ nhật được bao bởi các đa giác hình tam giác. Khối lăng trụ được bao bởi các đa giác hình tam giác và hình chữ nhật. Khối hình chóp được bao bởi các đa giác hình tam giác và hình chữ nhật.

Multiple Select

Which of the following are common types of polyhedra mentioned in the lesson?

• Rectangular prism

• Regular prism

• Regular pyramid

• Sphere

Fill in the Blanks

A polyhedron is a solid bounded by

polygons.

Open Ended

Explain the difference between a rectangular prism, a regular prism, and a regular pyramid as shown in the lesson.

Open Ended

Describe the dimensions of the projections of a rectangular prism as shown in the lesson.

Multiple Choice

Which of the following shapes is formed by the cross-section (shaded area) of a cylinder along the axis shown in the diagram?

• Rectangle

• Triangle

• Semicircle

• Ellipse

Fill in the Blanks

A solid of revolution is created by rotating a plane figure around a fixed

.

Multiple Select

Which of the following shapes can be obtained as the cross-section of a solid of revolution?

• Rectangle

• Triangle

• Semicircle

• Square

Open Ended

Explain the difference between the projection of a polyhedron and the projection of a solid of revolution.

Multiple Choice

What is the shape of the top view projection (B) of a cylinder?

• Rectangle

• Circle

• Triangle

• Square

Open Ended

Describe the projections of a cylinder when viewed from the front, top, and side.

Open Ended

After learning about orthographic projection and simple geometric shapes, what questions do you still have or what would you like to explore further about this topic?

Multiple Choice

What is the main purpose of using orthographic projection in technical drawing?

• To create artistic representations of objects

• To show multiple views of an object for accurate construction

• To add color and shading to objects

• To make objects look three-dimensional
