Fundamentals Of Electric Circuits

First Steps to Determine Node Voltages is?

• Select a node as the reference node
• Apply KCL to each of the n-1 nonreference nodes
• Solve the resulting simultaneous equations to<br />obtain the unknown node voltages
• Select Mesh
• Apply KVL

Analysis that provide general procedure for analyzing circuits using node voltages as the circuit variable is

• Noda analysis
• Mesh Analysis
• Circuit Analysis
• KCL
• KVL

To simply matters, we shall assume in nodal analysis that circuit don't contain

• current circuits
• voltages circuit
• transistor circuit
• Resistor Circuit
• Capacitor circuit

In nodal analysis,we are intersted to finding

• current circuits
• voltages circuit
• transistor circuit
• Resistor Circuit
• Capacitor circuit

Nodal analysis have . . . steps

• 1
• 2
• 3
• 4
• 5

Ground that used when chassis acts as reference point for all circuits is

• chasis ground
• electric ground
• basis ground
• ground
• capacitor ground

the reference point in an electrical circuit from which voltages are measured is

• Ground
• electric ground
• basis ground
• Plastic ground
• capacitor ground

To solve matrix equation, we can use

• Elimination
• Cramer's rule
• Newton Law
• 1&2
• 2&3

For determine node voltages, we have to apply….. to each of the n-1 nonreference nodes. Then use Ohm’s law to express the …….currents in terms of node voltages

• KVL
• KCL
• Node
• Element
• Branch

which of the following choices is capasitors equations

• V = I.R
• R = V/I
• q = C.V
• W = F.s
• P=W/t
