1.

The Abbreviation ‘CAD’ stands for_____________.

a)

Craft And Design

b)

Computer Assisted Coding

c)

Craft Aided Drawing

d)

Computer Aided Drafting

2.

What is the primary unit of measurement used in technical drawing?

a)

inch

b)

ft

c)

cm

d)

mm

3.

What does the Abbreviation ‘DWT’ stands for?

a)

Drawing with type

b)

Drawing Topic

c)

Drawing file

d)

Drawing Template

4.

Which of following should be entered in the command bar To activate the line command?

a)

Lin

b)

Li

c)

L

d)

Ln

5.

By pressing F8 on the keyboard, what are turning on/off?

a)

Ortho

b)

Isoplane

c)

Grid

d)

Osnap

6.

To activate the Copy command from the command bar the following abbreviation should be entered:

a)

C

b)

Co

c)

Cop

d)

C

7.

To activate the TR command from the command bar the following abbreviation should be entered:

a)

Trim

b)

Trim right

c)

Turn

d)

Type

8.

When saving an AutoCAD drawing the file type should be:

a)

.dwt

b)

.dg

c)

.dwg

d)

.drw

9.

When drawing in 2D, what axis do you NOT work with?

a)

Z

b)

Y

c)

X

d)

WCS

10.

How much long will a line from 0,5 to 5,5 be ________

a)

5mm

b)

10mm

c)

15mm

d)

None of the above

11.

Which command is used to create a circle in AutoCAD?

a)

Circle

b)

Arc

c)

Ellipse

d)

Polyline

12.

How much long will a line from 0,6 to 6,6 be ________

a)

6

b)

16

c)

65

d)

none of the above

13.

When the ortho mode is on, you can only draw lines that are

a)

Diagonal & Straight

b)

Horizontal & Vertical

c)

Vertical & Diagonal

d)

All the above

14.

Which of the following represents OFFSET?

a)

b)

15.

What is the minimum allowable number of layers in a drawing?

a)

0

b)

5

c)

2

d)

1

16.

WHAT IS THIS SYMBOL?

a)

LINE

b)

ARC

c)

POLYLINE

d)

CURVE

17.

Once you have selected offset the first operation is to ______ and the cursor will turn into a square.

a)

click on the screen

b)

enter a distance

c)

copy a line

d)

window an object

18.

What does the Trim command do?

a)

Cuts off object past specific point

b)

Cuts off object at the starting point

c)

Cuts off the object in half everytime

19.

What do the letters UCS?

a)

Uniform Calculator System

b)

Universal Coordinate System

c)

Universal CAD Settings

d)

United CAD System

20.

What is the measurements used in technical drawing

a)

Metric system

b)

Universal CAD Settings

c)

Imperial system

d)

Uniform Calculator System

21.

Which is corresponded to zoom mouse wheel?

a)

Zoom in / zoom out

b)

pan & scan

c)

extents / all

d)

scale
